DPR Gemini GMN40: digital finishing system for sheets
The DPR Gemini GMN40 is a compact automatic sheet feeding and cutting system from the DPR Gemini Series, suitable for cutting labels, stickers, and small packaging. The device processes sheets measuring 210–353 mm in width and 279–500 mm in length with an accuracy of 0.3 mm, completely autonomously and without operator intervention.
Product Description
DPR GMN40
This model from the DPR Gemini Series supports media sizes with a width of 210 to 353 mm and a length of 279 to 500 mm, ideal for standard formats and smaller productions.
Discover the complete DPR Gemini series here.
Item number DPRGMN40
Manufacturer number:
| Type product | Device, Finishing machine |
|---|---|
| Application | Labels, Packaging |
| Brand | DPR |
| Volume | Professional for smaller volumes |
| Availability | Available |
| Automatic sheet capacity | Approximately 150 sheets – with automatic feeder |
| Media width (min-max) | 210 – 350 mm (8.25” – 13.77”) |
| Media length (min-max) | 279 – 500 mm (11.69” – 19.68”) |
| Interface & Software | Cutting Manager Software (Windows XP and above) – cutting management tool |
| Registration system | The sensor mounted on the cutting head detects the marks on the media and compares their position with the original values from the digital file. The Gemini software then automatically adjusts linear and angular deviations by correcting the cutting lines. |
| Synchronization method | Two or four registration marks |
