Virgo 14PL Digital label finishing

SKU: DPRVRG14PL
brand: DPR
DPR

Easily unroll, laminate, digitally die-cut, roll up excess label material and then rewind. 2 versions: Virgo 14PL can cut up to 122mm wide and Virgo 22PL up to 225mm wide

Read More

Virgo is a compact desktop finishing system that unwinds, laminates labels for durability, digitally die cuts, removes excess label material around each die-cut shape, slit, and rewinds offering you everything to professionally cut and finish labels.

The system provides a very accurate label finishing solution using cutting plotter technology with reduced dimensions. This allows you to cut different types of materials and shapes on the fly without the added cost of dies.

The unit is also equipped with a cutter management tool that works in tandem with a camera forming an integrated optical

black-mark registration system providing cutting speed optimization and avoiding synchronization issues.

The Virgo’s core features offer the user full flexibility, limitless variations in label design with a smooth workflow. The Virgo digital label finisher is truly the perfect on-demand short run label finishing solution for those using a digital color label printers and presses.

Some benefits of using Virgo:

» Short run in-house label production reducing cost and inventory requirements
» Producing full bleed labels will no longer be a nightmare
» Laminating option for labels for added durability (no need for special media)
» No need to order pre-die cut label rolls
» Desktop size unit
» No need to set up a minimum gap between labels when printing in full bleed (Saves media).

Label face in or face out:

Thanks to an easy button equipped on Virgo, you can choose how obtain the finished rolls of label.

This button allows the user to control the direction of the rotation on rewinder core

holder giving, you the user, the ability to choose whether to have the finished label rolls facing in or facing out.This added benefit makes the Virgo a complete machine for all of your business needs.

Virgo Software

Virgo software works together with a camera forming an integrated optical black-mark registration system.

With this software, the operator can import the cutting files created on Adobe Illustrator or Corel Draw which is also used to create the black marker.

The Virgo is equipped with a camera used to detect the black-mark printed on the media. This camera assist the software in detecting the black-mark created inside the cutting file.

This process tells the plotter when and where to start cutting the media.



Artikelnummer: DPRVRG14PL

Specifications

Input / Output max. roll diameter: 200mm
Minimum media width: 100mm
Maximum media width: 140mm
Maximum cutting width: 122mm
Minimum slitting width: 19mm
Number of slitting blades: up to 6
Lamination module: YES
Dimensions: L = 130 cm
H = 65 cm
W = 75 cm
Weight (estimated): 100kg
Roll core size: 76mm
Minimum / Maximum label length: 10mm/200mm
Maximum media thickness: 0.25mm
Maximum cut speed: 600mm/s in all directions
Warranty: One year parts and labor. Usage limitation may apply

Videos

Here you can watch the video of the Virgo.

Virgo 14

Brochure

Brand

DPR

Type product

Device, Finishing machine

Type of label finish

Digital – Knive
